The L298N H-Bridge module, like in the image below, has two connection configurations available. So, test the electrical characteristics of any H-Bridge module before connecting to the Raspberry Pi. There are other popular H-Bridge modules about but not all are compatible with the Raspberry Pi. This H-Bridge module is compatible with the Raspberry Pi, however, other L298N configurations might not be as compatible. You can get more information about this module here.

#L298n motor driver raspberry pi zero w driver#

For now, I am just focussing on the H-Bridge control logic.Ī typical H-Bridge module I am using here is an L298N Dual H-Bridge DC motor driver module.

#L298n motor driver raspberry pi zero w full#

The full H-Bridge wiring schematic is not included in this case since a full example schematic is shown above.

#L298n motor driver raspberry pi zero w how to#

The Python code examples provided show how to set up PWM for two different H-Bridge configurations. GPIO PWM Python 3 Code Examples Raspberry Pi and L298N H-Bridge Connection Schematic

API – Output Devices - GPIO Zero Documentation.

Adjusting the PWM duty cycle, for instance, will allow variable RPM control of DC motors.Īlso, check for additional initialisation settings and other class properties and methods at the following link. So consequently a re-map function may be required to convert controller output value ranges to PWM duty cycle ranges. The duty cycle range is between 0.0 and 1.0 inclusive. Then during robot control operation, the duty cycle is the only value I will change for PWM robot speed control. Then I use property setters frequency and value to set the initial PWM frequency and duty cycle. While using (BCM) pin numbering, I initialize a new object I call leftWheels with a Raspberry Pi GPIO pin Number.

The above python code shows the initial PWM setup. From gpiozero import PWMOutputDevice leftWheels = PWMOutputDevice(21) equency = 1000 leftWheels.value = 0.50 Then I take a look at how the GPIO PWM might interface with an H-Bridge module. However, GPIO Zero API is well documented and information on all available classes is here. And while there are a few other ways to get PWM working on the Raspberry Pi, the Python class I will be focusing on is PWMOutputDevice. GPIO PWM Python 3 APIįirst, I will take a look at the GPIO Zero API as a quick brief on how to get PWM working. I think this is an ideal approach for makers beginning to build their own R/C robot project.

Then use GPIO PWM through the GPIO Zero API. In any case, from my own tests, I am confident that I can get some decent DC motor control by attaching an H-Bridge module directly to the Raspberry Pi.

#L298n motor driver raspberry pi zero w software#

But I believe the PWM is software driven using a shared clock source and might involve DMA channels.

I admit at this point I do not know how the GPIO PWM is implemented on the Raspberry Pi. GPIO PWM GPIO PWM Output at 1200Hz Frequency Now, I take a look at how to drive a typical H-Bridge module, connected to a Raspberry, with GPIO PWM. I have already covered R/C controller input using a game controller here. This will help keep the Python code elements of the robot control software modular. Furthermore, it is worth noting to keep hardware driver software code routines separate from robot control logic routines. So, getting a bit of understanding of how the hardware works first will help create the rest of the robot control software. This is especially true where the robot vehicle is a skid steer type. There is a lot that goes on in code between R/C controller input and H-Bridge DC motor driver output.

Furthermore, H-Bridge diver code examples with wire connection illustrations are included. Through Python programming, I look at how to interface with a typical H-Bridge DC motor driver. In this article, I look at using the Raspberry Pi GPIO PWM for DC motor control.
